NETGEAR ANT224D10

ANT224D10-10000S - ProSAFE antenne Antenne directionnelle Type-N 10 dBi

Ref : ANT224D10-10000S
143,52 €
HTVA
Taxe Ecotrel : 0,05 €
SKU
ANT224D10-10000S
Marque
Catégorie
Antennes

NETGEAR ANT224D10 - Antenne - Wi-Fi - 10 dBi - directionnel - extérieur, intérieur

ProSAFE antenne Antenne directionnelle Type-N 10 dBi
ANT224D10-10000S
High speed. Big range. Serious durability.

Optimal for building-to-building deployments outdoors or floor-to-floor connectivity indoors, boost your RF signal in a specific direction for long range point-to-point connections with ProSAFE® 10 DBI Directional antenna at wireless 802.11n speeds.

Optimize WLAN Range and Power with the ProSAFE® 10 dBi 2x2 Indoor/Outdoor Directional Antenna

The ANT224D10 2.4 GHz antenna provides extended range connectivity for point-topoint wireless bridges at wireless 802.11n speeds. With a maximum range of 8.5 KM, the ANT224D10 enables high speed connections for building-to-building deployments. Additionally, this antenna can be used indoors for floor-to-floor connectivity or to provide a narrow beam of coverage. Due to the multiple streams of traffic in the 802.11n specification, this antenna requires two antenna cables, which are available in a variety of lengths. It includes several mounting options and comes with wall/pole mounting hardware. Cables are sold separately.

NETGEAR ProSafe® line of antennas and accessories for 802.11b, 802.11g and 802.11n devices give you multiple options for maximizing the reach and performance of your wireless infrastructure devices. Every WLAN deployment is unique. With both directional and omni-directional antennas, indoor and outdoor options, low-loss cables, mounting hardware, and other accessories, installers can customize a wireless solution that meets the requirements of even the most challenging applications.
Caractéristiques
Couleur du produitGris
Distance de fonctionnement maximum8500 m
Longueur de câble0,3 m
PolarisationPolarisation verticale
Type d'antenneAntenne directionnelle
Type de connecteur AntenneType-N
UtilitéIntérieure et extérieure
Conditions environnementales
Température d'opération-30 - 80 °C
Poids et dimensions
Hauteur40 mm
Largeur240 mm
Poids700 g
Profondeur240 mm
représentation / réalisation
Bande de fréquence2.4 - 2.5 GHz
Niveau de gain de l'antenne (max)10 dBi
Plan E (angle d'ouverture à 3 dB)32°
Plan H (angle d'ouverture à 3 dB )33°
Standards réseauIEEE 802.11n
